Butterfly Valves

Butterfly and Ball Valves

0

Butterfly and Ball Valves whether manually or automatically operated can be used in most liquid product applications in the food processing, pharmaceutical and chemical industries. Typically they are used as two way valves for on/off manual or automated isolation or control.

Butterfly Valves are available from ½” to 8” (DN15-DN200) and Ball Valves 1” to 4” (DN25-DN100). Materials of construction are 316 L Stainless Steel with a variety of Seat Materials including EPDM, NBR, VMQ or FPM. Connections Include Clamp, SMS, RJT, FIL-IDF. Electric and Pneumatic Actuation is available with both open/closed indication and positioning available as an option.



Butterfly Valves

0

Full range of Butterfly valves manufactured and tested to API 609 & API 598 standards

  • Sizes from DN40 to DN2400
  • General purpose and high performance valves with a full range of body and trim materials in wafer and
    lugged / tapped flanged designs
  • Available with electric or pneumatic actuation

Butterfly Valves

0

Stainless Steel, Carbon Steel and Cast/Ductile

Wafer, Flanged and Lugged

Soft Seated and High Performance

Butterfly Valves

0

Stainless Steel, Carbon Steel & Cast/Ductile Iron

Wafer, Flanged & Lugged

Soft Seated and High Performance Metal Seated

Ball Valves

Ball Valves

0

Stainless Steel, Carbon Steel and Cast/Ductile Iron

Flanged, Screwed, Socket Weld, Butt Weld, Wafer Pattern, 3-Way

Ball Valves

0

Stainless Steel, Carbon Steel & Cast/Ductile Iron

Flanged, Screwed, Socket Weld, Butt Weld, Wafer Pattern, 3-Port, Soft & Metal seated

Butterfly and Ball Valves

0

Butterfly and Ball Valves whether manually or automatically operated can be used in most liquid product applications in the food processing, pharmaceutical and chemical industries. Typically they are used as two way valves for on/off manual or automated isolation or control.

Butterfly Valves are available from ½” to 8” (DN15-DN200) and Ball Valves 1” to 4” (DN25-DN100). Materials of construction are 316 L Stainless Steel with a variety of Seat Materials including EPDM, NBR, VMQ or FPM. Connections Include Clamp, SMS, RJT, FIL-IDF. Electric and Pneumatic Actuation is available with both open/closed indication and positioning available as an option.



Floating Ball Valves

0

Full range of Floating Ball Valves to BS 5351

  • Size range ½” to 12”
  • Full and reduced bore
  • Up to ANSI Class 2500
  • Carbon Steel, Low Temp Carbon Steel, and Stainless Steel available from stock
  • Other material grades including Alloy and Duplex Steels upon request
  • Supplementary Testing RT, MT, DP, PMI Ect and Special Metallurgy available upon request
  • Firesafe certification to API 607 / BS 6755 Pt. 2 and ISO 10497

Trunnion Ball Valves

0

Full range of Trunnion Mounted Ball Valves to API 6D and BS 5351

  • Size range 2” to 56”
  • Full and reduced bore
  • Up to ANSI Class 2500
  • Carbon Steel, Low Temp Carbon Steel, and Stainless Steel available as standard
  • Other material grades including Alloy and Duplex Steels upon request
  • Supplementary Testing RT, MT, DP, PMI Ect and Special Metallurgy available upon request
  • Firesafe certification to API 607 / BS 6755 Pt. 2
    and ISO 10497

Power-tork

Electric Actuators

0

Our range of EL Electric Actuators are available in 110VAC, 240VAC and 24VDC voltages to a standard specification as listed below. They are designed to operate quarter turn ball valves, butterfly valves and dampers. We are also able to supply special requirements such as multi-turn, fail safe and ATEX in a variety of sizes on a short delivery time.

  • Waterproof to IP67
  • Temp Rating -40° to +70°c
  • Anti Condensation Heater
  • 2 off M20 Cable Entries
  • Mechanical Travel Stops
  • 4 off limit switches
  • 75% Duty Rating
  • Constant Torque output, no drop off when running
  • Self-locking epi-cyclical gearing with turn de-clutchable manual over-ride (no push in or pull out hand-wheel)
  • Die cast aluminium housing & cover (polyurethane coating with stainless fastener)
  • 4-20mA and 0-10V control options.
  • Optional local controls.
  • Optional IP68 double sealed housing.

Pneumatic Actuator

0

We stock a full range of PT Series Rack & Pinion Pneumatic Actuators available for next day dispatch worldwide. These are suitable for operation of ball, butterfly valves and dampers and have been recognized by prominent companies worldwide as a reliable and dependable actuator. The stainless steel version of this actuator is currently being used in some of the most arduous locations worldwide.

  • Rack and pinion design
  • Single and Double Acting Versions in 90⁰, 120⁰ & 180⁰ configuration
  • Fully – Coated Extruded Aluminium body as standard
  • PTFE coated and Stainless Steel options available
  • ISO S5211/DIN 3337, VDI/VDE 3845, Namur Standards
  • Approvals include, ATEX, GOST, ISO, SIL 2
  • 100% Certified European Manufacture & Componentry
  • Actuators available with torque of up to 10,000 n.m.

Positioners

0

Our PT1000 Positioner is a electro-pneumatic positioner which has been providing safe and trouble-free operation in an extremely wide range of process industries worldwide for many years. The electro-pneumatic positioner is particularly distinguished by its versatility. The valve positioner safely and reliably controls the complete variety of control valves, and can additionally handle challenging applications.

  • Suitable for both linear and rotary actuators
  • single or double acting
  • Intrinsically safe and explosion proof housings,
  • Available with limit switches and feedback.
  • ATEX; CSA & FM approvals available on request

Switchboxes

0

Our standard PT850 Switchbox is a compact aluminium switchbox with visual indication suitable for a wide range of applications. Easy to install, small and robust it is the ideal choice for reliable feedback. We also supply bespoke Switchboxes with mechanical switches and proximity sensors in a range of designs including stainless steel, PTFE coated and to Exia/Eexd standards.

  • Visual position indicator
  • -20~+80⁰c
  • 2 off Mechanical Switches (Proximity Sensors also available)
  • Quick set spring loaded cam for easy adjustment
  • 8 point terminal strip
  • Dual wire conduit entries
  • Captive cover bolts
  • Easy Mounting brackets
  • Optional IP68 version available, ½” NPT entries
